Stainless steel IBC Tanks
Stainless Steel IBC Tanks for Sale: the perfect solution to meet your storage requirements. When it comes to storage solutions, finding reliable, durable and cost-effective options can be challenging.
PRODUCT DESCRIPTION
Description
Stainless steel IBC tanks are gaining growing popularity across all industries for their versatility and dependability. Also known as Intermediate Bulk Containers, these tanks are engineered for safe, efficient storage and transportation of various liquids and materials.
1000-litre Stainless Steel IBC Tank for Chemical Acids
Our intermediate bulk containers are available in standard sizes listed on this page, with custom sizes available upon customer request.
Our metal tanks are fabricated from 304-series stainless steel or alternative alloys for storage and transport of liquid materials. Tank corners feature a 2-inch radius design for improved structural strength and easier cleaning. The integrated sloped tank base enables complete draining.
Multiple lid and valve options are available. The 22-inch manhole cover facilitates cleaning and inspection. Welding procedures and material surface finishes of the tanks can be customised per client requirements.
Intermediate Bulk Containers can be tested and labelled in compliance with UN / DOT regulations for liquid handling. These tanks also satisfy food-grade requirements set by the USDA and FDA.
Product Specifications
1. Material: SUS304, SUS316L stainless steel. The tanks deliver excellent corrosion resistance and wear resistance for extended service life. Suitable for conveying a wide range of powdery materials.
2. Surface Finish: Mirror-polished inner surface; pickled outer surface.
3. Fitted with handles, castor wheels and self-locking devices for easy transportation. Well-thought-out structural design supports forklift handling, stacking and hoisting operations.
4. Sloped-base design allows fast, complete drainage and easy cleaning with no dead corners.
5. Constructed from premium-grade stainless steel by argon-arc welding. Resistant to acid, alkali and high temperatures. Elegant appearance, rational structure and easy-to-clean surfaces.
6. Nameplate marked with company name and medium contained inside.
Advantages
· Stacking angle bars for container stacking, complete with crane hook attachments
· Deep-drawn base minimises dead corners; outlet recess plus direct flange-mount outlet valve permit full tank drainage and simple cleaning
· Forklift guard protects the discharge valve against damage from forklift tines
Drawings and special custom requirements are welcome.
FAQ
Q: How about payment term, payment safety and delivery time?
A: We accept 40% deposit, balance before shipment. And Irrevocable L/C at sight.Delivery time is 7 to 30 days. It is according to order quantity.
Q: How could we confirm the products?
A: Our professional engineers will follow up all the designs and ajustments according to your requirement.OEM and ODM available.
Q: What services can we provide?
A:Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Cardl,Western Union,Alipay;
Q: How can I know your machine works well?
A: Before delivery, we shall test the machine working condition for you.
Q: What's your MOQ?
A: 1 set.
Completed Technical Specification Guide for Stainless steel IBC Tank
1. Product Overview
The stainless steel Intermediate Bulk Container (IBC tank) is a reusable, high-strength, closed-type fluid storage and transportation container, complying with ISO, IMDG and UN dangerous goods packaging standards. It is designed for medium-volume cyclic storage, transfer and temporary fermentation of liquid materials in chemical, food, beverage, pharmaceutical, bio-fermentation and new energy industries.
2. Executive Standards
This product is manufactured, inspected and certified in accordance with the following international and industrial specifications:
·
ISO 12048: General specification for intermediate bulk containers
·
·
IMDG Code: International Maritime Dangerous Goods Code
·
·
UN31A/Y: Dangerous goods packaging certification (Class II/III hazardous liquid)
·
·
EN ISO 1461: Hot-dip galvanizing frame anti-corrosion standard
·
·
FDA 21 CFR 177.2600: Food-grade material safety standard
·
·
GMP: Pharmaceutical and biotech sanitary manufacturing standard
·
·
JB/T 4735: Stainless steel container manufacturing specification
·
3. Core Technical Parameters
Standard model: 1000L (500L/1500L/2000L customizable)
Item | Technical Data |
Nominal Capacity | 1000L |
External Dimension | 1130×1130×1420mm |
Tank Body Material | SUS304(1.4301) / SUS316L(1.4404) |
Wall Thickness | 2.0–3.0mm |
Frame Material | Hot-dip galvanized steel / Full stainless steel |
Tare Weight | 170–230kg |
Bottom Structure | Integral sloped bottom, 100% no residual liquid |
Top Manhole | DN400/DN457 clamp type manhole, EPDM/Silicone/PTFE gasket |
Discharge Valve | 2-inch stainless steel lockable ball valve |
Ventilation Port | 1-inch pressure balance vent valve |
Forklift Mode | Four-way forklift entry |
Stacking Capacity | 3 layers stacking (full load static state) |
Lifting Mode | Integrated lifting lugs, crane-liftable |
Working Temperature | -20℃ ~ +120℃ |
Working Pressure | Normal pressure / Micro positive pressure (customizable) |
Surface Treatment | Pickled & passivated / Electrolytic polishing (Ra≤0.4μm) |
Certification | UN31A/Y, FDA Food Grade, GMP compliant |
4. Material Performance Description
4.1 SUS304 Stainless Steel
General-purpose food-grade stainless steel, with excellent oxidation resistance and corrosion resistance, stable chemical properties, no precipitation of harmful substances. Suitable for daily chemical, food, drinking water, general solvent storage, pH 3–11 medium environment, low cost and high cost performance.
4.2 SUS316L Stainless Steel
Molybdenum-containing low-carbon stainless steel, effectively resists chloride ion pitting corrosion, acid and alkali erosion, and high-temperature oxidation. It is suitable for high-corrosion working conditions such as brine, chemical reagents, fermentation broth, new energy electrolyte, and pharmaceutical intermediates. Ultra-low carbon design avoids intergranular corrosion, meeting high-standard sanitary and chemical industry requirements.
5. Structural Design Features
5.1 Integral Sloped Bottom
One-piece stamping sloped bottom structure, no dead angle at the bottom. The liquid can be completely discharged through the bottom ball valve without residual material, which solves the material waste and bacterial growth problems of traditional flat-bottom IBCs, and is convenient for CIP online cleaning.
5.2 Sealed Sanitary Structure
The top manhole adopts quick-clamp sealing design, matched with food-grade EPDM/silicone/PTFE gasket, with good air tightness and no leakage. The independent pressure balance vent valve avoids negative pressure suction and tank deformation during discharging, ensuring stable material output. All welding seams are polished smoothly without welding pores and burrs.
5.3 Reinforced Load-bearing Frame
The outer frame adopts hot-dip galvanized steel or all-stainless-steel integral welding structure, with high structural strength, strong impact resistance and compression resistance. Four-way forklift holes and integral lifting lugs are reserved, supporting manual forklift, electric forklift handling and crane hoisting, and can be stacked in multiple layers after full load, saving storage space.
5.4 Safe Discharge System
The bottom is equipped with a lockable stainless steel ball valve, which is easy to control the flow. The valve body has good corrosion resistance, no leakage, and supports quick disassembly and cleaning. It can be matched with quick connectors, filters and other accessories to realize closed pipeline conveying and avoid material secondary pollution.
6. Production & Process Standards
·
Welding: Full argon arc welding, no solder residue, uniform weld formation
·
·
Surface treatment: Industrial pickling and passivation to remove oxide scale, enhance anti-corrosion performance; sanitary grade optional electrolytic polishing (inner wall Ra≤0.4μm)
·
·
Sealing: All gaskets adopt food-grade high-temperature resistant materials, aging resistance and long service life
·
·
Pressure test: 100% air tightness test and water pressure test before delivery, no leakage
·
·
Deburring: Full internal and external polishing and deburring, no dead angle cleaning
·
7. Inspection & Acceptance Criteria
7.1 Appearance Inspection
The tank body has no deformation, scratch, rust and crack; the weld is smooth and flat without pores, trachoma and virtual welding; the frame is firm without loose welding; the surface galvanizing layer is uniform and free of peeling.
7.2 Performance Test
·
Air tightness test: Keep 0.05MPa pressure for 30min, no pressure drop and no air leakage
·
·
Water pressure test: Fill with water and stand for 24h, no water seepage and no deformation
·
·
Stacking test: Static stacking 3 layers (total load 3000kg) for 48h, no structural deformation
·
·
Lifting test: Full load lifting for 10min, no loose parts and no deformation
·
7.3 Material Inspection
Provide stainless steel material certificate, component test report, food-grade certification and UN dangerous goods packaging qualification report to ensure material consistency and compliance.
8. Application Scope
·
Food & Beverage Industry: Wine, vinegar, beverage, syrup, edible oil, fermentation broth storage and turnover, GMP sanitary production
·
·
Pharmaceutical & Biotech Industry: Liquid medicine, biological reagent, vaccine intermediate, sterile material storage
·
·
Fine Chemical Industry: Solvent, surfactant, weak acid and alkali medium, daily chemical raw material storage and transportation
·
·
New Energy Industry: Lithium battery electrolyte, new energy raw material anti-corrosion storage
·
·
Hazardous Goods Transportation: Class II/III non-explosive hazardous liquid road and sea transportation with UN certification
·
9. Advantages & Service Life
Compared with traditional plastic IBC tanks, stainless steel IBCs have high temperature resistance, low temperature resistance, aging resistance and no chemical reaction with materials. The overall service life can reach 10–15 years, which is reusable and environmentally friendly. The fully polished inner wall is not easy to hang dirt, convenient for manual cleaning and automatic CIP cleaning, meeting high-standard sanitary production requirements.
10. Maintenance Instructions
·
After each use, clean the tank body and valve pipeline to avoid material residue curing and breeding bacteria
·
·
Regularly check the sealing gasket and vent valve, replace aging accessories in time to ensure air tightness
·
·
Avoid strong impact and scratch on the tank body during handling and stacking
·
·
Long-term idle storage requires cleaning and drying, and placing in a dry and ventilated environment
·
·
Prohibit long-term storage of strong corrosive media beyond material tolerance to avoid tank body corrosion
·
